    Corner Sheet Pile
    Corner Sheet Pile

    Corner sheep pile is a newly developed type produced by rolling, which eliminate the need for welding and other fabrication processes, and is far lighter in weight.
    The corner interlocking sections have been improved in shape to prevent loosening.

    Single Pile

    Sections

    Width

    Devlation

    Perimeter

    Height

    Thickness

    Weight

    Weight

    Moment

    Modulus

    W

    Angle

    Single Pile

    H

    T

    Per pile

    Per Wall

    of Inertia

    of Section

    mm

    o

    mm

    mm

    Kg/m

    Kg/m2

    cm4/m

    cm3/m

    BMS1

    500

    69.5

    9.5

    4.5

    163

    58.9

    117.8

    747

    188

    BMS2

    500

    71

    11

    4.5

    164

    68.2

    136.4

    852

    216

    BMS3

    500

    72

    12

    4.5

    164.7

    74.4

    148.8

    931

    236

    BMS4

    500

    72.5

    12.5

    4.5

    165

    77.5

    155

    971

    246

    BMS5

    500

    72.7

    12.7

    4.5

    165.2

    78.8

    157.6

    990

    251
