L/S Sheet Pile
L Profile sheet piles
Profile
|
Dimension
|
Mass
|
Moment
of Inertia
|
Elastic
section
Modulus
|
Width
B
|
Height
H
|
Thickness
T
|
Per Pile
|
Per wall
|
mm
|
mm
|
mm
|
Kg/m
|
Kg/ m2
|
Cm4/m
|
Cm3/m
|
BML1.5
|
700
|
100
|
3.0
|
21.4
|
30.6
|
724
|
145
|
BML2
|
700
|
150
|
3.0
|
22.9
|
32.7
|
1674
|
223
|
BMl3
|
700
|
150
|
4.5
|
35.0
|
50.0
|
2469
|
329
|
BML4
|
700
|
180
|
5.0
|
40.4
|
57.7
|
3979
|
442
|
BML5
|
700
|
180
|
6.5
|
52.7
|
75.3
|
5094
|
566
|
BML6
|
700
|
180
|
7.0
|
57.1
|
81.6
|
5458
|
606
|
S Profile sheet piles
Profile
|
Dimension
|
Mass
|
Moment
of Inertia
|
Elastic
section
Modulus
|
Width
B
|
Height
H
|
Thickness
T
|
Per Pile
|
Per wall
|
mm
|
mm
|
mm
|
Kg/m
|
Kg/ m2
|
Cm4/m
|
Cm3/m
|
BMS4
|
600
|
260
|
3.5
|
31.2
|
41.7
|
5528
|
425
|
BMS5
|
600
|
260
|
4.0
|
36.6
|
48.8
|
6703
|
516
|
BMS6
|
700
|
260
|
5.0
|
45.3
|
57.7
|
7899
|
608
|
BMS8
|
700
|
320
|
5.5
|
53.0
|
70.7
|
12987
|
812
|
BMS9
|
700
|
320
|
6.5
|
62.6
|
83.4
|
15225
|
952
|
Application:
Cofferdam(land); Cofferdam(Water); Low embankment; Deep foundation pit; Shallow underground excavation; Light-duty Sea Use; Heavy-duty Sea Use; Underground water quality control. etc.
Pictures:
|
