Stainless Steel Plate

Share to:

  • Stainless Steel Plate

    Stainless Steel Plate
    Stainless Steel Plate

    Stainless Steel Plate
    Stainless Steel Plate

    Introduction:

    Stainless steel plate refers to resistancee of air,steam,water and other weak corrosive mediums and acid,alkali,salt and other chemical corrosive medias.Stainless steel plate also known as acid-resistant stainless steel plate.The corrosion resistance of stainless steel plate with lower carbon content and added element Cr.

    Rolling specifications range: Thickness:1-80mm,Width:1200-2500mm,Length:3000-18000mm.


    Additional services for stainless steel plates: Cutting and welding according to customers' required sizes.

    Stainless steel plate can be made by hot rolling and cold rolling , including the thickness of 0.31-3.0 mm sheet and 2.5-16 mm slab.

    Hot-rolled stainless steel plate

    Cold-rolled stainless steel plate

    Lower hardness

    Hardness

    Easy to process

    Processing is relatively more difficult

    Good plasticity and ductility

    Not deformed

    Lower intensity

    High intensity

    Poor surface quality
    ( Easily oxidized )

    High surface finish

    Slab

    Sheet

    Hot-rolled stainless steel, mechanical properties not as good as cold-rolled, but there are good toughness and ductility. Cold-rolled stainless steel plate due to the good hardening, toughness is low.

    In order to ensure all kinds of stainless steel yield strength, tensile strength, elongation and hardness and other mechanical properties to meet the requirements, prior to delivery must be stainless steel annealing, solution treatment, aging heat treatment.

    Finish

    Thickness

    Characteristics

    Applications

    No. 1

    3.0mm~50.0mm

    Finished by hot-rolling, annealing and pickling,

    characterized by white pickled surface

    Chemical industry equipment,

    Industrial tanks

    No. 2B

    0.3mm~6.0mm

    Finished by heat treatment,

    pickling after cold rolling,

    followed by skin pass line to be

    more brighter and smooth surface

    General Application Medical Instruments,

    Tableware

    No. BA
    (Bright Annealed)

    0.5mm~2.0mm

    Bright heat treatment after cold rolling

    Kitchen utensil,

    kitchen ware,

    architectural purpose

    No. 4

    0.4mm~3.0mm

    Polishing with No. 150 to No.180

    mesh abrasivesThe most popular finishes

    Milk & Food processing acilities,

    Hospital Equipment, Bath-tub

    No. 8

    0.5mm~2.0mm

    A mirror-like reflective surface

    by polishing with finer abrasives over 800 mesh

    Reflector, Mirror, Interior-Exterior decoration forbuilding

    HL(Hair Line)

    0.4mm~3.0mm

    Finished by continuous linear polishing

    Architectural purposes,

    escalators, kitchen ware vehicles

    Standard of Stainless Stell Plate:

    Thickness
    ( mm)

    Width*Length(mm & ft)

    1000*2000

    916*2438

    1219*2438

    1219*3048

    1219*6096

    1524*3048

    1524*6096

    3'*8'

    4'*8'

    4'*10'

    4'*20'

    5'*10'

    5'*20'

    0.3

    7.07

    0.4

     9.43

    0.5

     7.93

     8.83

     11.8

     14.7

    0.6

     9.52

     10.6

     14.1

     17.7

    0.7

     11.1

     12.4

     16.5

     20.6

    0.8

     12.7

     14.1

     18.9

     23.6

     29.5

    0.9

    14.3

     15.9

     21.2

      26.5

     33.2

    1.0

     15.9

     17.7

     23.6

     29.5

     36.8

    1.2

     19.0

     21.2

     28.3

      35.4

     44.2

    1.5

     23.8

     26.5

     35.4

      44.2

     55.3

    2.0

     31.7

     35.3

     47.1

      58.9

     73.7

    2.5

     58.9

      73.7

     92.1

    3.0

     70.7

       88.4

     111

    4.0

     94.3

     118

     147

    5.0

    118

     147

     184

    6.0

     141

     177

      354

     221

     442

    7.0

     165

     206

     412

     258

     516

    8.0

     189

     236

     471

     295

     589

    9.0

     212

     265

      530

     332

     663

    10.0

     236

     295

     589

     368

     737

    11.0

     259

     324

     648

     405

     810

    12.0

     283

     354

      707

     442

     884

    13.0

     306

     383

     766

     479

     958

    14.0

     330

     412

     825

     516

     1031

    15.0

     354

     442

     884

     553

     1105

    16.0

     377

     471

     943

     589

     1179

    17.0

     401

     501

     1002

     626

     1252

    18.0

     424

     530

     1061

     663

     1326

    19.0

    448

     560

     1120

     770

     1400

    20.0

     471

     589

     1179

     737

     1473

    21.0

     495

     619

     1237

     774

     1547

    22.0

     518

     648

     1296

     810

     1621

    23.0

     542

     678

     1355

      847

     1694

    24.0

     566

     707

     1414

    884

      1768

    25.0

     589

     737

     1473

    926

     1842

    28.0

     660

     825

     1660

     1031

     2063

    30.0

      707

     884

     1768

     1105

     2210

    32.0

     754

     943

     1886

     1179

     2358

    35.0

      825

     1031

     2062

     1289

     2579

    38.0

     896

     1120

     2239

     1400

     2800

    40.0

     943

     1179

     2357

     1473

     2947

    42.0

     990

     1237

     2457

     1547

     3094

    45.0

     1061

     1326

     2652

     1658

     3315

    48.0

     1131

     1414

     2829

     1768

     3536

    50.0

     1178

     1473

     2946

     1842

     3684

    STANDARD

     STEEL GRADE

    ASTM A240/A240M

    SS201,SS202,SS301,SS302,SS302B,SS303,SS304,SS304L,SS304N,

    SS304H,SS309S,SS310S,SS316,SS316L,SS316N,SS316H,SS316Ti,SS904L

    AISI

    AISI 201,AISI 202,AISI 301,AISI 302,AISI 302B,AISI 303,AISI 304,

    AISI 304L,AISI 304N,AISI 304H,AISI 309S,AISI 310S,AISI 316,

    AISI 316L,AISI 316N,AISI 316H,AISI 316Ti,AISI 904L

    JIS

    SUS 201,SUS 202,SUS 301,SUS 302,SUS 302B,SUS 303,SUS 304,

    SUS 304L,SUS 304N,SUS 304H,SUS 309S,SUS 310S,SUS 316,

    SUS 316L,SUS 316N,SUS 316H,SUS 316Ti,SUS 904L
