    Clad/Composite Steel Plate
    Clad/Composite Steel Plate

    Introduction:

    Clad steel plate,means the metal plate covered with a layer of another metal plate to achieve reducing the cost and owned highly effective solution in steel industrial.The materials mostly composite carbon steel plate and stainless steel plates.Clad steel plate mainly used in anti-corrosion,pressure vessels manufacturing,electrical construction,petrochemical, pharmaceutical, light industry, automobile and other industries.

    1, specifications range:8 mm to 300 mm thicknessWidth 1500 mm to 4020 mmLength is 3000 mm to 18000 mm,The biggest single heavy 25 tons of steel plate;
    2, delivery status:According to the properties and user needs, steel plate can be hot rolling and controlled rolling, annealing, normalizing, tempering, normalizing + tempering, conditioning and state delivery;
    3, detection and thickness direction performance:To produce additional testing requirements and Z15-Z35 tensile (thickness direction) steel plate, also can performance by ASTM, A770 standards to provide Z performance steel plates.

    Other additional services for Clad steel plate:NACE,Ultrasonic examation,Welding and cutting and other processing in our plant.

    Application:

    Used to make linear accelerator recessed, cyclotron cylinder, chemical container, hydropower station with a high wear-resisting pipe and other structures.

    Specification:

    Product

    Steel Grade / Number

    Standard

    Clad/Composite

    Steel

    Plate

    TU1/20g
    0Cr13Ni5Mo/Q235A
    0Cr13Ni5Mo/16Mn

    GB13238
    GB8165



    STEEL GRADE

    Q235B+304,Q345B+304,Q235B+304L,Q345B+304L,S355JR+410,A537CL1+410,A516Gr70+410,

    A516Gr70(NACE)+410,P265GH+410,S355JR+304,S355JR+304L,S355JR+316L,A516Gr70+304,

    A516Gr70+304L,A516Gr70+316,A516Gr70+316L,A537CL1+304,A537CL1+304L,A537CL1

    +316L,P265GH+904L,A516Gr70+904L,A537CL1+904L

    Note:

    1. Can Z15-Z35 each brand production of layered tear resistance (thickness direction performance steel plate.)

    2. Production specifications: 8 mm-40 mm thickness and width 1500 mm to 3900 mm, length of 3000 mm to 18000 mm. Agreement by both parties, which can supply the more big specifications of the steel plate.

    3. According to the properties and delivery state user needs, steel plate can be hot rolling and controlled rolling, annealing, normalizing, tempering, is fire and tempering, conditioning and state delivery.
