U Type Tank Condensing Units
U Type Tank Condensing Units Size
| Unit Model | Receiver volume | Overall size (mm) | Installation size (mm) | connecting line（mm） | Weight | ||||
| A | B | C | E | F | Suction pipe | Liquid supply pipe | |||
| dm3 | mm | mm | mm | mm | mm | Æ | Æ | kg | |
| BMMAEFHUC-001 | 8 | 990 | 753 | 857 | 950 | 530 | 1-1/8 | 1/2 | 133 |
| BMMAEFHUC-002 | 12 | 1240 | 803 | 852 | 1200 | 580 | 1-3/8 | 5/8 | 195 |
| BMMAEFHUC-003 | 14 | 1500 | 854 | 867 | 1460 | 630 | 1-3/8 | 5/8 | 210 |
| BMMAEFHUC-004 | 18 | 1500 | 903 | 875 | 1460 | 680 | 1-3/8 | 5/8 | 215 |
| BMMAEFHUC-005 | 22 | 1500 | 953 | 867 | 1460 | 730 | 1-5/8 | 3/4 | 261 |
| BMMAEFHUC-006 | 30 | 1606 | 1003 | 1004 | 1566 | 780 | 1-3/8 | 3/4 | 280 |
| BMMAEFHUC-007 | 38 | 1704 | 1053 | 1108 | 1664 | 830 | 2-1/8 | 3/4 | 326 |
| BMMAEFHUC-008 | 45 | 1704 | 1053 | 1108 | 1664 | 830 | 2-1/8 | 7/8 | 344 |
