Specification
|
|
Display Size
|
6＂
|
Resolution
|
640×480
|
External dimension
|
178mmx170mmx84.45mm
|
Language
|
Simple Chinese、English
|
Voltage Range
|
11～35V DC
|
Display mode
|
TFT LCD COLOR Display
|
Operating mode
|
Adjustable backlight button/shortcut button/T9keyboard
|
Power dissipation
|
≤10W
|
Environment
|
Temperature -10℃～50℃
|
installation
|
embedded installation/Scaffolding installation
|
GPS function
|
Receive Frequency 1575.42MHz together with 12channels/C/A
|
Adopt high speed stable technology
|
Positioning accuracy：<15m;95% accuracy
|
Antenna：external connect
|
positioning time：cold start 45s;warm start15s
|
Navigation performance
|
Way points：6000 points
|
signs：6000 points
|
route：200 routes—–each route contains 99 way points
|
track：≥200 routes（way points≥60000 points per route）
|
float data：the ship'position/fishing zone/direction and information of date
|
include the tide and compass
|
Equipment List
|
Display Unit T80F 1unit
|
Installation material
|
Operation Manual
|
GPS Antenna
|
Sonar function （option）
|
DPS (digital processing system)/High resolution to the continuous sampling
|
auto/manual measuring range；auto/manual gain
|
operating power：50KHz or 200KHz or 50/200KHz （optional）
|
transmitting power：300W/600W/1000W/1800W (optional)
|
AIS function （option）
|
AIS target/name/MMSI/distance/location/speed
|
AIS cursor information inquire/AIS listing inquire
|
AIS alarming circle setting/AIS-SOS alarming
|
Interface
|
GPS output：RS-232/NMEA0183.4800bps
|
AIS input/output：RS-232/NMEA0183.38400bps
|
sonar input/output：RS-232/NMEA0183.115200bps
|
SD card interface
|
