Working frequency |
9200MHz～9500MHz
|
Polarization
|
Horizontal polarization
|
Antenna
|
Horizontal beam omnidirectional <± 2dB; vertical beam ± 12.5 °
|
Transmitter
|
Scan rate forward scan 7.5 ± 1μs; reverse scan 0.4 ± 0.1μs; radiation power ≥ 400mw; response delay <0.5μs
|
Receiver
|
Effective sensitivity ≤-50dBm; recovery time <10μs
|
Operating temperature
|
-20 ° C to + 55 ° C
|
Storage temperature
|
-30 ° C to + 65 ° C
|
Battery power
|
Standby time 96 hours, continuous work 8 hours
|
Size
|
Maximum diameter: 118mm (without mounting bracket and bracket accessories); Maximum height: 299.5mm (without special hand lever)
|
Weight
|
<1.5kg
|
