Marine AIS 8 Inches

Date:2020-06-23  Click:319   Share to:

  • Marine AIS 8 Inches


    Marine 8 inches GPS AIS

    Specification



    Display Size

    8

    Resolution

    640×480

    External dimension

    303mmx215mmx99mm

    Display mode

    TFT LCD COLOR Display

    Operating mode

    Adjustable backlight button/shortcut button/T9keyboard

    Language

    Simple ChineseEnglishTraditional Chinese

    Voltage Range

    1135V DC

    Power dissipation

    ≤15W

    Safe distance of Compass

    ≥1.5 m

    AIS function

    Receive Frequency 156025-162.025MHz"

    Default Channel CH2087/CH2088"

    Band Width 25KHz

    Modulation Mode GMSK

    Receive sensitivity

    Superior to-107dBm

    GPS Receiver

    Adopt high speed stable technology

    Positioning accuracy<15m/95% accuracy

    positioning timecold start 45s/warm start15s

    Navigation performance

    Way points6000 points

    signs6000 points

    route200 routes/each route contains 99 way points

    track≥200 routesway points≥60000 points per route

    include the tide and compass

    Interface

    GPS outputRS-422/NMEA0183/4800bps

    AIS input/outputRS-422/NMEA0183/38400bps

    sonar input/outputRS-422/NMEA0183/115200bps

    GPS Antenna InterfaceBNC base/impedence50Ω

    VHF Antenna InterfaceUHF base/impedence50Ω

    Power interface24V DC

    Environment

    Temperature -15℃50℃

    Protection Level

    IP44

    Certification

    CCS certification

    Equipment List

    Display Unit AIS9000-08 1unit

    Installation material

    Operation Manual

    GPS Antenna
