Marine GPS AIS Chart Plotter
Display Size, 12＂
Resolution, 800×600
External dimension, 366mmx285mmx98mm
Display mode, TFT LCD COLOR Display
Operating mode , Adjustable backlight button/shortcut button/T9keyboard
Language , Simple Chinese、English、Traditional Chinese
Voltage Range , 11～35V DC
Power dissipation, ≤25W
Safe distance of Compass, ≥1.5 m
AIS function , Receive Frequency 156．025-162.025MHz”
Default Channel CH2087/CH2088″
Band Width 25KHz
Modulation Mode GMSK
Receive sensitivity, Superior to-107dBm
GPS Receiver ,Adopt high speed stable technology
Positioning accuracy：<15m/95% accuracy
positioning time：cold start 45s/warm start15s
Navigation performance , Way points：6000 points
signs：6000 points
route：200 routes/each route contains 99 way points
track：≥200 routes（way points≥60000 points per route）
include the tide and compass
Interface , GPS output：RS-422/NMEA0183/4800bps
AIS input/output：RS-422/NMEA0183/38400bps
sonar input/output：RS-422/NMEA0183/115200bps
GPS Antenna Interface：BNC base/impedence50Ω
VHF Antenna Interface：UHF base/impedence50Ω
Power interface：24V DC
Environment, Temperature -15℃～50℃
Protection Level, IP44
Certification , CCS certification
Equipment List , Display Unit AIS9000-12 1unit,Installation material,Operation Manual,GPS Antenna
|
