Specification
|
|
Display Size
|
15＂
|
Resolution
|
1024×768
|
External dimension
|
272mmx305mmx100mm
|
Display mode
|
TFT LCD COLOR Display
|
Operating mode
|
Adjustable backlight button/shortcut button/T9keyboard
|
Language
|
Simple Chinese、English、Traditional Chinese
|
Voltage Range
|
11～35V DC
|
Power dissipation
|
≤30W
|
Safe distance of Compass
|
≥1.5 m
|
AIS function
|
Receive Frequency 156．025-162.025MHz"
|
Default Channel CH2087/CH2088"
|
Band Width 25KHz
|
Modulation Mode GMSK
|
Receive sensitivity
|
Superior to-107dBm
|
GPS Receiver
|
Adopt high speed stable technology
|
Positioning accuracy：<15m/95% accuracy
|
positioning time：cold start 45s/warm start15s
|
Navigation performance
|
Way points：6000 points
|
signs：6000 points
|
route：200 routes/each route contains 99 way points
|
track：≥200 routes（way points≥60000 points per route）
|
include the tide and compass
|
Interface
|
GPS output：RS-422/NMEA0183/4800bps
|
AIS input/output：RS-422/NMEA0183/38400bps
|
sonar input/output：RS-422/NMEA0183/115200bps
|
GPS Antenna Interface：BNC base/impedence50Ω
|
VHF Antenna Interface：UHF base/impedence50Ω
|
Power interface：24V DC
|
Environment
|
Temperature -15℃～50℃
|
Protection Level
|
IP44
|
Certification
|
CCS certification
|
Equipment List
|
Display Unit AIS9000-15 1unit
|
Installation material
|
Operation Manual
|
GPS Antenna
|
