1. Advanced technology: parallel and receiving 12 channels at the same time, can lock 12 satellite positioning, abnormal quickly;
2. Powerful function: 500 waypoints, and 20 routes, shifting anchor alarm, yaw alarm and make navigation easier;
3. Chinese interface: original localization, the whole Chinese operation, more convenience for our work;
4. Unique backlight: advanced luminescence method, the background light more bright, show more clear.
5. Good calculating: the most advanced signal decoding and processing, is the machine to provide accurate
and stable speed and course information .
Standard configuration:
specification
Marine navigation antenna AZ - 4 a
Marine with navigation power cable
GPS - 128 c/FF - 100 mounting bracket
Display: liquid crystal display 10.8 cm, 102 x 65 pixel lattice
Physical size:
Temperature range: - 15 ° C - + 70 ° C
Outer shell: waterproof, moisture-proof, prevent salt fog
Power supply voltage: 10 - 40 VDC
Power consumption: 13.8 V power supply, the biggest power 4 w
Pass way: 12 channel
Rev. Dynamic: hot start 15 seconds, cold start 45 seconds, automatic positioning for 5 minutes
Positioning accuracy: 15 meters
Data update rate: 1 SEC/ 1, continuously and automatically
Speed degree: 0.05 m/SEC
Acceleration: 3 g
Joint mouth: RS - 232
Interface Settings: NMEA0180, 0182,018 3 and DGPS
Waypoint: 500
Route: 20, each 30 point
Navigation mark: 10
Track point: 1024
Alarm: drag anchor, arrived, yaw, close and clock alarm
Coordinate system: via/latitude, UTM/UPS, other coordinate system and the user defined
