Display: 10.4 "inch true color display
Echo: Eight kinds of color (background color) is based on the echo intensity, Monochrome display is also available.
Background color: choose from blue, shallow blue, white, black.
Basic range:
m: 5/10/20/40/80/150/80/150 15/30
inch: 15/30/60/120/60/120 /
Fathoms: 3/5/10/20/10/20/10/20
Passi/Braza: 3/5/10/30/50/100/50/100
Basic change range in the system menu
Range change: biggest 300 meters (1000 feet, 150 fathoms, 1000 PB)
Expand the range: 2 and 4, and 5 times range
Expanding bottom lock scale: 5/10 meters, 10/20 ft, 2/5 fathoms, 2/5 PB
Automatic mode: automatic adjustment range and sensitivity
Display mode: 50 KHz or 200 KHz version: normal, expand, A - depending on the area 50 KHZ & (200 KHZ double-frequency)
Version: the high frequency (200 KHZ), low frequency (50 KHZ),
Dual-frequency (200 KHZ and 50 KHZ 1/2 of each screen),
Expand (200 KHZ and 50 KHZ to expand to A - depending on the area.
Expand shows: tag, lock at the bottom and bottom to expand
Display speed freezes, 1/8, 1/4, 1/2, 1/1, 2/1.
Transmission frequency: 50 KHZ, 200 KHZ and 50 & 200 KHZ (dual-band, KF - 293 df).
Output power: 1 kw and 2 kw - 293 - a (KF)
|
