High-resolution thin true color LCD
Built-in large capacity storage
High sensitivity GPS receiver
A variety of display mode
Chart picture
Fishing explore images
navigation data
Double-picture (chart/sounding)
satellite data
Electronic chart drawing quickly
Chart picture shows track at the same time, route and route data
Second-ranking depth function is optional 50 KHZ or 200 KHZ Low water
depth data real-time display to chart picture
7 color order target displays Low
automatic control mode Low and
high-speed processor
low power consumption
Description:
GPS receiving characteristics
The receiver 12 channel receiver
2. Receive frequency L1 (1575.42 MHz)
3. The accuracy of about 10 m
4. The positioning time 12 seconds (hot start)
5. 900 Knotts tracking rate
Navigation:
Display: 10.4 "inches colored ultra-thin LCD, 640 X 480 pixels
display mode
Optional picture is as follows:
- the full screen chart patterns
- the full screen yaw model
- the full screen mode of satellite data KP - 1038
- a full-screen fishing explore mode (),
- double-picture (chart + sounding) (KP - 1038),
Coordinate: On the north
Land shows: Customized.
Shining beacon mode: open or shut down
Chart display range scale: 1/2000 ~ 1/25000000
Nm: 0.1 ~ 1500 nm
Latitude range Between 85 ° and 85 ° S of N
8. Draw the first 5 seconds to 60 points or 0.01 to 10 nm
9. The storage capacity of 8000 track and 8000 route
10. Plan sailing navigation navigation or route navigation ,
11. The range 7 color plotter is composed of 200 points
12. Alarm anchor zone, arrived, the yaw, range, voltage, satellite
13. Data NMEA - 0183 version 2.0 and RTCM - 104
14. The international/local time to manually enter the jet lag
Sounding features:
Color display: 7 color scale display objects
Mode optional picture as below:
- the full screen Separately display
- middle magnification
- split screen shows the bottom enlarged In the above mode on/off A
- the Scope display
3. 50 KHZ frequency or 200 KHZ
The division of vertical or horizontal split screen mode
depth range M: 2.5, 5, 10, 15, 20, 30, 40, 50, 80, 100, 150, 200, 100, 150, 1000
FM: 2.5, 5, 10, 15, 20, 30, 40, 50, 80 100, 150, 200, 100, 150, 1000
BR: 2.5, 5, 10, 15, 20, 30, 40, 50, 80 100, 150, 200, 100, 150, 1000
FT: 5, 10, 20, 30, 40, 50, 80, 100, 150 200, 300, 500, 200, 300, 3000
The horizontal offset: 1 unit steps from 0 to 999 Meters/fathhoms/braccia
Speed to stop, 1/16, 1/8, 1/4, 1/2, 1/1
Deep fish alarm alarm and alarm
The output power standard power 300 w, 600 w, 1000 w is optional)
