Parameters
|
( 1 ) Display |
5.6-inch TFT LCD |
( 2 ) Echo Color |
8 colors (including background color) according to echo intensity.
Monochrome display is also available. The background color is
selectable from blue, light blue, white and black.
|
( 3 ) Basic Range |
Meters : 5/10/20/40/80/150/200/300
Feet : 15/30/60/120/200/400/600/1000
Fathoms : 3/5/10/20/40/80/100/150
Passi / Braza : 3/5/10/30/50/100/150/200
The basic ranges can be changed on the system menu. |
( 4 ) Range Shift |
Up to 300 meters (1000 feet, 150 fathoms, 200 passi/braza) |
( 5 ) Zoom Range |
Times 2, 3, 4 and 5 ranges |
( 6 ) Bottom Lock Expansion Range |
5/10 meters, 10/20 feet, 2/5fathoms , 2/5 passi/braza |
( 7 ) Auto Mode |
Automatic adjustment of range and gain |
( 8 ) Display Mode |
High Frequency (200K), Low Frequency (50K),
Dual (200K and 50K 1/2 display on each),
Zoom (200K and 50K zoom) and A-scope Display
|
( 9 ) Zoom Display |
Marker Zoom, Bottom Zoom and Bottom-lock Expansion |
( 10 ) Display Advance Speed |
Lines/TX : Freeze, 1/8, 1/4, 1/2, 1/1, 2/1 |
( 11 ) TX Frequency Output power |
50 and 200kHz (alternately transmitted), 300W
|
