5 Inches Marine GPS chart plotter Fully support CMAP chart
Model:BMMNCCP001
Features:
5”TFT LCD with 480*272 resolution,LED backlight,wide angle of view
Elegant and stylish designed with IPX6 water-proof standard,support flush or swivel mounted.
User friendly HMI&keypad operation allows quick and easy to operate
Smoothly adjust backlight,excellent readability
AIS input ports,convenient connection AIS equipment,dynamically display AIS targets on the chart.
AIS ship alarm,CPA and TCPA,speed,yaw,anchor alarm function
More accurate tidal data for query at any time
Installation method:embedded installaton and multi-angle mesa insatallation
Products parameters
type
|
BMMNCCP-001
|
display
|
5 inch
|
Display resolution
|
480*272
|
waterproof
|
IPX6
|
LCD brightness
|
400cd/m²
|
Weight
|
2.5kg
|
waypoint
|
200000points
|
routes
|
800lines
|
marks
|
10000points
|
tracks
|
10000points
|
Others function
|
Loading chart,SD card upgrade,Expand the chart of
memory space,support voice prompts and alarms
|
Power supply
|
12-36V,with the powder meter protection circuit
|
Accuracy
|
GPS:<15m(95%)DGPS(WAAS
EGNOS MSAS):<3m(95%)
|
Updating frequency
|
1 time/second
|
Data interface
|
NMEA 0183Output 2 ports;AIS input 1 port
|
Operating temperature
|
-15℃~+55℃
|
Storange temperature
|
-20℃~+60℃
|
dimension
|
20.3*13.3*7.83cm
|
|
