12.1 Inches Marine chart plotter Fully support CMAP chart
Model：BMMNCCP002
Features
12.1” TFT LCD with 800*600 resolution,LED backlight,wide angle of view
Elegant and stylish designed with IPX6 water-proof standard,support flush or swivel mounted.
User friendly HMI&keypad operation allows quick and easy to operate
Smoothly adjust backlight,excellent readability
AIS input ports,convenient connection AIS equipment,dynamically display AIS targets on the chart.
AIS ship alarm,CPA and TCPA,speed,yaw,anchor alarm function
More accurate tidal data for query at any time
Installation method:embedded installaton and multi-angle mesa insatallation
Products parameters
type
|
BMMNCCP002
|
display
|
12.1 inch
|
Display resolution
|
SVGA800*600
|
GPS receiver
|
12channels GPS
|
GPS frequency
|
1575.42MHZ
|
Updating frequency
|
1time/second
|
Tracks
|
800 piece,500 thousand point
|
Routes
|
200 lines
|
Way point
|
6000 point
|
Data interface
|
NMEA-0183/RS422(AIS Input 1 ports,GPS output 3
ports,0183 input 3 ports)
|
Other function
|
Intelligent voice,distance,tide,yaw alarm,MOB,the ship’s
position tracking,backlight brightness
adjustment,compass interface,analog navigation
|
Power supply
|
DC24V
|
Fix mode
|
Desktop or flush mounting
|
Operating temperature
|
-15℃~+55℃
|
Dimension
|
311*298*129.7mm
|
|
