Stainless Steel Flanged High Pressure Emergency Cut-off Solenoid Valve

Material

Stainless steel

Type

Two way

Connection way

Flange

DN

25 mm

Medium

Liquefied petroleum gas

Flow direction

One way

Structure

Plunger type

Pressure

High pressure

Working temperature

Normal

Standard

National

DN(mm)

Pressure

Voltage

Coil power

Medium temperature

Note

(Mpa)

(V)

(℃)

Action:Straight,forerunner, differential pressure, pulse

1

3-5
6-7
8-10
11-15
16-20
21-25
26-30
31-35
36-40
41-45
46-50
51-70
71-80
81-90
91-100
101-110
111-120
121-130
131-200

AC:
380
220
110
36
24

DC:
220
110
24
12

DC(W)
1.5
2
4.5
8
10
15
30
35
AC(A)
0.1
0.3
0.5
0.75
1
1.25

-200

-40
+80

+120

+200

+350

+400

3

5

Control way:Normal close,normal open

8

10

Protect:Ordinary, explosion-proof, waterproof

15

20

Connection:Threaded(male,female),flange(concave and convex flange)

25

32

40

50

Fluid medium:Air,steam,water,oil,refrigerant, preservative

65

Body material:(304,316,316L)
stainless steel,cast steel

80
