Regulating Valve

DN        (mm)

15

20

25

32

40

50

65

80

100

125

150

200

PN        (Mpa)

1.6                  4.0

Flow     (m3/h)

5

7

10

16

25

40

63

100

160

250

400

630

Rated travel      (mm)

6

8

10

14

20

30

40

Temperature adjust range (℃)

0~120       :        100~250

Regulation accuracy  (℃)

+-1   ~    +-5

Suitable mediums

steam、water、oil、gas

Allowable leakage

hard sealed

10-4XRated Capacity

soft sealed

0

Capillary length

3m,5m,10m

Bulb embedded depth

270,430,630

source nipple

3/4"   1"
