GJ41X Manual Glue Set Pinch Valve

Date:2020-06-22 Click:439 Share to:

DN	Main outline dimensionsconnection dimensions						Weight (KG)
DN	L	D	D1	D2	b	Z-Ф	Weight (KG)
20	135	105	75	55	16	4--14	2.5
25	145	115	85	65	16	4--14	3
32	160	135	100	78	18	4--18	4
40	180	145	110	85	18	4--18	6
50	210	165	125	100	20	4--18	7.5
65	250	185	145	120	20	4--18	9.5
80	300	190	160	135	22	4--18	16
100	350	215	180	155	22	8--18	20
125	430	245	210	185	25	8--18	28
150	500	280	240	210	25	8--23	43
200	650	335	295	265	32	8--23	80
