GJ941X Electric Pinch Valve

Date:2020-06-22 Click:338 Share to:

DN	Pressure Mpa	Working pressure Mpa	L	L1	L0	D	D1	Z-ø	H	Electric actuator					Weight (kg)
DN	Pressure Mpa	Working pressure Mpa	L	L1	L0	D	D1	Z-ø	H	Type	A	B	D0	Kw	Weight (kg)
25	0.6	0.6	160	124	31	115	85	4--14		ZA5-14	443	133		0.12	18
32			165	145	40	140	100	4--18
40			190	157	50	150	110	4--18
50			210	160	60	160	125	4--18		ZA10-18	552	425	305	0.25	71
65			270	199	74	180	145	4--18		ZA15-15	552	425	305	0.37	80
80			300	222	88	195	160	4--18		ZA30-18	552	425	305	0.75	92.9
100			350	250	106	215	180	8--18		ZA30-18	552	425	305	0.75	101
125			430	318	134	245	210	8--18
150			500	350	158	280	240	8--23	1000
200			650	446	206	335	295	8--23	1174	ZA-45-18	766	390	305	1.1	265
250			800	516	256	395	350	12--23
300			950	562	304	445	400	12--23
Adoption standard Design and manufacturing ：Q/JBGN02 Structure length：Q/JBGN02 Conecting flange size：JB78PN1.0MPa
