Wafer Type Circular Plate Check Valve
Model
|
DN
(mm)
|
d
(mm)
|
L(mm)
|
L(mm)
|
I Type
|
II Type
|
PN 1.0
|
PN 1.6
|
PN 2.5
|
PN 4.0
|
BMMVPPSCV001
|
50
|
50
|
15
|
22
|
109
|
109
|
109
|
109
|
BMMVPPSCV002
|
65
|
65
|
15
|
22
|
129
|
129
|
129
|
129
|
BMMVPPSCV003
|
80
|
80
|
15
|
22
|
144
|
144
|
144
|
144
|
BMMVPPSCV004
|
100
|
100
|
15
|
24
|
164
|
164
|
170
|
170
|
BMMVPPSCV005
|
125
|
125
|
16
|
26
|
194
|
194
|
186
|
186
|
BMMVPPSCV006
|
150
|
150
|
19
|
29
|
221
|
221
|
226
|
226
|
BMMVPPSCV007
|
200
|
200
|
29
|
43
|
295
|
275
|
286
|
293
|
BMMVPPSCV008
|
250
|
250
|
29
|
43
|
330
|
331
|
343
|
355
|
BMMVPPSCV009
|
300
|
300
|
38
|
50
|
380
|
386
|
403
|
420
|
BMMVPPSCV010
|
350
|
350
|
41
|
52
|
440
|
446
|
460
|
477
|
BMMVPPSCV011
|
400
|
400
|
51
|
62
|
491
|
498
|
517
|
549
|
BMMVPPSCV012
|
450
|
450
|
51
|
62
|
541
|
558
|
567
|
574
|
BMMVPPSCV013
|
500
|
500
|
65
|
80
|
596
|
620
|
627
|
631
|
BMMVPPSCV014
|
600
|
600
|
70
|
90
|
698
|
737
|
734
|
750
|
Material:Carbon steel,stainless steel
Pressure:1.0-4.0 mpa
Working temperature:≤400℃(hard seal),≤120℃(soft seal)
Medium:Oil,water,soda acid liquid
It has a simple structure,good appearance,light weight,easy installation,etc.
|
