J41H Series Steel Stop Valve

Date:2020-06-19 Click:356 Share to:

Model	Tpye	DN mm	Dimension(mm)								Weight kg
Model	Tpye	DN mm	L	D	D1	D2	b	z-Фd	H	DO	Weight kg
BMMAEPSSV001	J41H-PN16	10	130	90	60	40	14	4×Ф14	198	120	5
		15	130	95	65	45	14	4×Ф14	200	120	5.5
		20	150	105	75	55	14	4×Ф14	243	140	7.3
		25	160	115	85	65	14	4×Ф14	253	160	8
		32	180	135	100	78	15	4×Ф18	280	160	12
		40	200	145	110	85	16	4×Ф18	312	200	16
		50	230	160	125	100	16	4×Ф18	321	200	16
		65	290	180	145	120	18	4×Ф18	325	240	22
		80	310	195	160	135	20	4×Ф18	355	240	31
		100	350	215	180	155	20	4×Ф18	415	280	45
		125	400	245	210	185	22	4×Ф18	460	320	80
		150	480	280	240	210	24	8×Ф23	510	360	97
		200	600	335	295	265	26	12×Ф23	590	360	169
