Application:
Applied to teaching experiments, research, testing and aging of electronic production lines, communications equipment maintenance, and other areas that require DC power supply.
Product characteristic:
1.Specification range:Output voltage 0~1000V, output current 0~200A, output power 0~20KW can be adjusted
2.Constant voltage adn current:Voltage and current from 0 to retaed number constant adjust, constant voltage and current change automatically.
3.Overvoltage protection: the number of voltage protection number continuously adjustable in 0~120%, Trip protection happens when output voltage exceed voltage protection value.
4.Short circuit protection: Under no circumstances allow long-term short circuit or short boot.
5.Intelligent: connet with PLC,to make remote control intelligent stablized power supply.
6.High adaptability.
Technical parameter
Input voltage
|
AC220V±10%, AC380V±10%
|
Input frequency
|
50Hz±10%
|
Output voltage
|
0~1000V
|
Output current
|
0~200A
|
Output power
|
0~20KW
|
Working term
|
Stable state automatically change
|
Ouput voltage and current
|
0~rated value
|
Constant voltage indicate
|
CV, green LED
|
Constant current indicate
|
CC, red LED
|
Working term
|
Long-term work at full capacity
|
Compressive strength
|
1500V 60S
|
Working temperature
|
-20℃~+40℃
|
Relative humidity
|
10%-90%
|
Product Model：
Output current
|
0~15V
|
0~30V
|
Type / power
|
Size (mm)
|
Type / power
|
Size (mm)
|
0~80A
|
WYJ-1580
|
1200W
|
350*500*675
|
WYJ-3080
|
2400W
|
350*500*675
|
0~100A
|
WYJ-15100
|
1500W
|
350*500*675
|
WYJ-30100
|
3000W
|
350*500*675
|
0~150A
|
WYJ-15150
|
2250W
|
350*500*675
|
WYJ-30150
|
4500W
|
350*500*675
|
0~200A
|
WYJ-15200
|
3000W
|
403*630*955
|
WYJ-30200
|
6000W
|
403*630*955
|
Output current
|
0~50V
|
0~60V
|
Type / power
|
Size (mm)
|
Type / power
|
Size (mm)
|
0~80A
|
WYJ-5080
|
4000W
|
350*500*675
|
WYJ-6080
|
4800W
|
350*500*675
|
0~100A
|
WYJ-50100
|
5000W
|
350*500*675
|
WYJ-60100
|
6000W
|
403*630*955
|
0~150A
|
WYJ-50150
|
7500W
|
403*630*955
|
WYJ-60150
|
9000W
|
403*630*955
|
0~200A
|
WYJ-50200
|
10000W
|
403*630*955
|
WYJ-60200
|
120000W
|
403*630*955
|
Output current
|
0~100V
|
0~120V
|
Type / power
|
Size (mm)
|
Type / power
|
Size (mm)
|
0~20A
|
WYJ-10020
|
2000W
|
350*500*675
|
WYJ-12020
|
2400W
|
350*500*675
|
0~30A
|
WYJ-10030
|
3000W
|
350*500*675
|
WYJ-12030
|
3600W
|
350*500*675
|
0~50A
|
WYJ-10050
|
5000W
|
350*500*675
|
WYJ-12050
|
6000W
|
403*630*955
|
0~80A
|
WYJ-10080
|
8000W
|
403*630*955
|
WYJ-12080
|
9600W
|
403*630*955
|
0~100A
|
WYJ-100100
|
10000W
|
403*630*955
|
WYJ-120100
|
12000W
|
403*630*955
|
0~150A
|
WYJ-100150
|
15000W
|
403*630*955
|
WYJ-120150
|
18000W
|
403*630*955
|
Output current
|
0~150V
|
0~200V
|
Type / power
|
Size (mm)
|
Type / power
|
Size (mm)
|
0~20A
|
WYJ-15020
|
3000W
|
350*500*675
|
WYJ-20020
|
4000W
|
350*500*675
|
0~30A
|
WYJ-15030
|
4500W
|
350*500*675
|
WYJ-20030
|
6000W
|
350*500*675
|
0~50A
|
WYJ-15050
|
7500W
|
403*630*955
|
WYJ-20050
|
10000W
|
403*630*955
|
0~80A
|
WYJ-15080
|
12000W
|
403*630*955
|
WYJ-20080
|
16000W
|
403*630*955
|
|
