Application:
The development of emergency switchboard SKE with frame combination structure,
we adopted the modular design, can make the arrangement of the switch and electrical room more matching;
Suitable for AC690V the following, single power in 20 kw to 800 kw ship AC system.
Model:
Product description:
Processing custom: yes.
Type: SKEE
Current rating: 3000 (A)
Short circuit close current: 3300 (KA)
Shell protection level: IP22
Physical size: according to the diagram (mm)
Product certification: ISO9001:2000
1. Function description:
When the main switchboard lose electric, emergency switchboard and main switchboard contact between switch will automatically
points brake; Emergency generator automatic startup, emergency generator switch automatic switching,
when power unit restore power, emergency generator switch automatic points brake, the main switchboard
and emergency switchboard contact between switch will automatically switching,
emergency generator switch points brake, delay 3 minutes, emergency generator automatic shutdown.
In order to improve the power supply reliability,
convenient customer maintenance, emergency switchboard all adopt separate electrical components.
2. structure characteristics:
Modular design;
Device cell compartment according to the module structure is divided into different units, convenient installation;
Agile into line way;
Stationary or drawer switch;
Rolling armrest;
In front of the plate lighting;
