Application:
Applied to teaching experiments, research, testing and aging of electronic production lines, communications equipment maintenance, and other areas that require DC power supply.
Products characteristic:
1.LED digital panel displays the output current and voltage values
2.Equipped with four rotating regulator, coarse and fine fraction, the operation more convenient and more accurate
3.With a steady flow function,CV/CC can be automatically converted
4.Output voltage and current from 0 to nominal value continuously adjustable
5.OVP / OCP multiple protection, safe to operate and longer lifespan
6.Low ripple, low noise, beautiful apperance , full-featured, excellent cost-effective
7.Continuous long-term work at full load
Technical parameter
Input volateg
|
AC220V/110V±10%
|
Input frequency
|
50Hz/60Hz
|
Output voltage
|
0-V can be adjusted
|
Output current
|
0-A can be adjusted
|
Stable voltage
|
Voltage stability
|
≦0.01%+3mV
|
Load stability
|
≦0.01%+5mV
|
Recovery Time
|
≦100us
|
Ripple noise
|
≦1mVrms
|
Temperature Coefficient
|
≦300PPM/℃
|
Stable current
|
Current stability
|
≦0.2%+3mA
|
Load stability
|
≦0.2%+3mA
|
Ripple noise
|
≦3mArms
|
Protection
|
Current automatic limit protection, short circuit protection, automatic protection
|
Working condition
|
Temperature
|
-10-40℃
|
Relative humidity
|
≦80%RH
|
Storing condition
|
Temperature
|
-10-80℃
|
Relative humidity
|
≦80%RH
|
Single output
Output current
|
0~15V
|
0~30V
|
0~60V
|
Type /Power
|
Type /Power
|
Type /Power
|
0~2A
|
WYJ-1502D
|
30W
|
WYJ-3002D
|
60W
|
WYJ-6002D
|
120W
|
0~3A
|
WYJ-1503D
|
45W
|
WYJ-3003D
|
90W
|
WYJ-6003D
|
180W
|
0~5A
|
WYJ-1505D
|
75W
|
WYJ-3005D
|
150W
|
WYJ-6005D
|
300W
|
0~10A
|
WYJ-1510D
|
150W
|
WYJ-3010D
|
300W
|
WYJ-6010D
|
600W
|
0~15A
|
WYJ-1515D
|
300W
|
WYJ-3015D
|
600W
|
WYJ-6015D
|
1200W
|
0~20A
|
WYJ-1520D
|
450W
|
WYJ-3020D
|
900W
|
WYJ-6020D
|
1800W
|
Double output
Output current
|
0~15×2V
|
0~30×2V
|
0~60×2V
|
Type /Power
|
Type /Power
|
Type /Power
|
0~2A×2
|
WYJ-1502B2
|
60W
|
WYJ-3002B2
|
120W
|
WYJ-6002B2
|
240W
|
0~3A×2
|
WYJ-1503B2
|
90W
|
WYJ-3003B2
|
180W
|
WYJ-6003B2
|
360W
|
0~5A×2
|
WYJ-1505B2
|
150W
|
WYJ-3005B2
|
300W
|
WYJ-6005B2
|
600W
|
0~10A×2
|
WYJ-1510B2
|
300W
|
WYJ-3010B2
|
600W
|
WYJ-6010B2
|
1200W
|
0~15A×2
|
WYJ-1515B2
|
600W
|
WYJ-3015B2
|
1200W
|
WYJ-6015B2
|
2400W
|
0~20A×2
|
WYJ-1520B2
|
900W
|
WYJ-3020B2
|
1900W
|
WYJ-6020B2
|
3600W
|
|
