Natural Gas Flame Arrester
Package
Model
|
DN
(mm)
|
D1(mm)
|
D2(mm)
|
L(mm)
|
PN1.0
|
PN1.6
|
PN2.5
|
PN4.0
|
BMMVPPSFA001
|
15
|
18×3
|
57×3.5
|
330
|
330
|
330
|
330
|
BMMVPPSFA002
|
20
|
25×3
|
57×3.5
|
330
|
330
|
340
|
340
|
BMMVPPSFA003
|
25
|
32×3.5
|
73×4
|
365
|
365
|
375
|
375
|
BMMVPPSFA004
|
32
|
38×3.5
|
73×4
|
375
|
375
|
390
|
390
|
BMMVPPSFA005
|
40
|
45×3.5
|
89×4
|
375
|
375
|
405
|
410
|
BMMVPPSFA006
|
50
|
57×3.5
|
108×4
|
420
|
420
|
445
|
465
|
BMMVPPSFA007
|
65
|
73×4
|
133×4.5
|
485
|
485
|
515
|
520
|
BMMVPPSFA008
|
80
|
89×4
|
159×4.5
|
505
|
505
|
560
|
560
|
BMMVPPSFA009
|
100
|
108×4
|
219×6
|
555
|
555
|
600
|
645
|
BMMVPPSFA010
|
125
|
133×4.5
|
273×8
|
615
|
615
|
670
|
720
|
BMMVPPSFA011
|
150
|
159×4.5
|
325×8
|
665
|
665
|
735
|
800
|
BMMVPPSFA012
|
200
|
219×6
|
377×9
|
940
|
940
|
1015
|
1100
|
BMMVPPSFA013
|
250
|
273×8
|
480×10
|
1030
|
1030
|
1150
|
1265
|
BMMVPPSFA014
|
300
|
325×8
|
529×10
|
1295
|
1295
|
1430
|
1545
|
BMMVPPSFA015
|
350
|
377×9
|
630×12
|
1300
|
1300
|
1430
|
1545
|
Body material:Carbon steel,Stainless steel 304/316
Fire arresting trim:Stainless steel
The seals:PTFE,Oil resistant rubber asbestos
Temperature:≤480℃
Pressure:15~25 mpa
Explosion-proof level:BS5501:IIA,IIB,IIC
Flame arrester suitable for installation in the transport of flammable gas pipe network.
|
