Marine Shore Connection Box AJ 20, AJ 100, AJ 250, AJ 600

Application:

Shore connection box for ship moored in terminal or into the dry-rock reason when the cabin generator all stop, get the shore power.

Model:

Appearance and installation dimensions:

Technical parameters:

Type	Current type	Pole number	Rated voltage	Switch rated current	Trip rated current
AZ100-30/2	DC	Positive and negative bipolar	220V	100	30
AZ100-50/2					50
AZ100-80/2					80
AZ100-100/2					100
AZ250-140/2				250	140
AZ250-200/2					200
AZ250-250/2					250
AJ20-10/2	AC single phase	Bipolar	220V	20	10
AJ20-20/2				20	20
AJ100-30/2				100	30
AJ100-50/2					50
AJ100-80/2					80
AJ100-100/2					100
AJ20-10/3	AC three phases	Three pole can connect to neutral	380V	20	10
AJ20-20/3				20	20
AJ100-30/3				100	30
AJ100-50/3					50
AJ100-80/3					80
AJ100-100/3					100
AZ250-140/2				250	140
AZ250-200/2					200
AZ250-300/2					250
AJ600-300/3				600	300
AJ600-400/3				600	400
