Application:
Fixed charger is applied to chanrging for constant voltage and power batteries.for example: wahsing machine, electric forklift, golf cart,
electric tour, electric patrol car, electric boat, electric ATV and so on. Adjustable constant current constant voltage charger is applied to
charging electrc system, communication system, train system, marine system, UPS, solar power system, photovoltic syatem and so on.
Product characteristic:
1.Wide range of AC input power.
2.Vertical design for easy mobility.
3.Electrostatic spraying, expen the life of shell, reinforced insulation
4.High brightness digital display.
5.Adjustable output current and voltage.
6.Constant voltage and current charging, expan the life of battery.
7.Fully automatic charging.
Specification:
Type
|
KZA-BCME
|
Input voltage
|
AC220V±10%, AC380V±10%
|
Input frequency
|
50Hz±5%
|
Output charging voltage
|
Floating charging 13.8V, BC 14.8V,
|
Output charging current
|
Set up charging current according to 10%-20% of the power
|
Working term
|
Automatic switching between constant current and constant voltage
|
Battery type
|
All kinds of battery
|
Battery size
|
6V, 12V,24V,36V,48V,72V,,96V,110V,220V,380V,500V etc.
|
Efficiency
|
≥90%
|
Ambient temperature
|
-20℃-45℃
|
Relative humidity
|
<90%
|
Working time
|
Long-term continuous operation
|
Radiating
|
Force cooled
|
Noise
|
65dB
|
Altitude
|
1000M
|
Product Lineup:
Model
|
Power
|
Capacity
|
Size
|
Weight
|
KZA-10A/12V
|
0.25
|
50~80
|
305*270*350
|
6
|
KZA-15A/12V
|
0.4
|
80-100
|
305*270*350
|
11
|
KZA-20A/12V
|
0.5
|
100-150
|
305*270*350
|
13
|
KZA-30A/12V
|
0.6
|
150-210
|
305*270*350
|
17
|
KZA-40A/12V
|
1
|
210-280
|
305*270*350
|
23
|
KZA-50A/12V
|
1.5
|
280-320
|
305*270*350
|
28
|
KZA-100A/12V
|
2.5
|
600-800
|
230*470*470
|
45
|
KZA-200A/12V
|
5
|
1200-1400
|
350*500*670
|
75
|
KZA-10A/24V
|
0.5
|
50-80
|
305*270*350
|
13
|
KZA-15A/24V
|
0.8
|
80-100
|
305*270*350
|
17
|
KZA-20A/24V
|
1
|
100-150
|
305*270*350
|
22
|
KZA-30A/24V
|
1.5
|
150-210
|
305*270*350
|
27
|
KZA-40A/24V
|
2
|
210-280
|
230*470*470
|
30
|
KZA-50A/24V
|
2.5
|
280-320
|
230*470*470
|
35
|
KZA-60A/24V
|
3
|
320-400
|
230*470*470
|
40
|
KZA-80A/24V
|
4
|
400-600
|
230*470*470
|
50
|
KZA-100A/24V
|
5
|
600-800
|
230*470*470
|
60
|
KZA-200A/24V
|
10
|
1200-1400
|
350*500*670
|
170
|
KZA-10A/36V
|
0.8
|
50-80
|
305*270*350
|
17
|
KZA-20A/36V
|
1.5
|
100-150
|
305*270*350
|
25
|
KZA-30A/36V
|
2
|
150-210
|
305*270*350
|
32
|
KZA-40A/36V
|
3
|
210-280
|
230*470*470
|
40
|
KZA-50A/36V
|
4
|
280-320
|
230*470*470
|
50
|
KZA-60A/36V
|
5
|
320-400
|
230*470*470
|
60
|
KZA-80A/36V
|
6
|
400-600
|
230*470*470
|
75
|
KZA-100A/36V
|
8
|
600-800
|
350*500*670
|
90
|
KZA-200A/36V
|
15
|
1200-1400
|
350*500*670
|
200
|
KZA-10A/48V
|
1
|
50-80
|
305*270*350
|
22
|
KZA-20A/48V
|
2
|
100-150
|
305*270*350
|
30
|
KZA-30A/48V
|
3
|
150-220
|
230*470*470
|
40
|
KZA-35A/48V
|
3.5
|
180-250
|
230*470*470
|
45
|
KZA-40A/48V
|
4
|
210-280
|
230*470*470
|
50
|
KZA-50A/48V
|
5
|
280-320
|
230*470*470
|
60
|
KZA-60A/48V
|
6
|
320-400
|
230*470*470
|
75
|
KZA-80A/48V
|
8
|
400-600
|
230*470*470
|
90
|
KZA-100A/48V
|
10
|
600-800
|
350*500*670
|
110
|
KZA-120A/48V
|
12
|
750-1000
|
403*630*955
|
180
|
KZA-150A/48V
|
15
|
800-1200
|
403*630*955
|
200
|
KZA-200A/48V
|
20
|
1200-1400
|
403*630*955
|
230
|
|
