Technical parameters
1. Input voltage: three-phase AC380V ± 10%, 50Hz;
Charging current 0-80A Adjustable setting.
2. Charging program: constant current → (constant pressure) are filling flow → (constant pressure) float.
3. Are charged voltage: 70V;
4. Float voltage: 60 V.
5. Environmental conditions: Operating temperature: (-10 ~ 45) ℃; Storage temperature: (-20 ~ 60) ℃;
Relative humidity: 90% (40 ± 2 ℃); atmospheric pressure: (70 ~ 106) kPa.
6. Dimensions: 255 (width) × 176 (high) × 540 (deep) mm.
7. machine weight: weight 16kg.
8. Efficiency: ≥86%.
9. Power factor: ≥0.85.
10. Dielectric strength: input to the shell and the output ≥ AC1500V; output on the shell ≥ AC500V.
11. Mean time between failures (MTBF): ≥50000h.
12. Thermal shutdown temperature threshold: (75 ~ 80) ℃.
|
