Output capacity |
200KVA
|
300KVA
|
400KVA
|
500KVA
|
600KVA
|
800KVA
|
1000KVA
|
1200KVA
|
1500KVA
|
Ac input
|
Input voltage
|
Three-phase 380 v to 480 v; Voltage allow fluctuation range: 323 v to 528 v
|
Input frequency
|
50Hz/60Hz±5%
|
Power factor
|
≥0.95O
|
Ac output
|
Output voltage
|
Three-phase 380 v plus or minus 15% (also can according to the customer request setting)
|
Output frequency
|
50Hz/60Hz (400 Hz optional)
|
Rated current
|
270A
|
405A
|
540A
|
675A
|
810A
|
1090A
|
1350A
|
1620A
|
2025A
|
Overload ability
|
150% 1 minute/ten minutes; 250% 2 seconds/twenty seconds; 400% protection
|
waveform
|
Sine wave, waveform distortion rate (THD) < 2%
|
Frequency stability factor
|
≤0.01%(0 ~ 100% load change output frequency constant)
|
Load stability factor
|
Load 0-100% output voltage change ≤3%
|
efficiency
|
≥85%(100% load)
|
Control mode
|
IGBT/SPWM sine pulse width modulation mode (high carrier)
|
Display function
|
LED display voltage, current, frequency, power factor, active power, reactive power display and measurement
|
Protection function
|
Over current, over voltage, under voltage, short circuit, open phase protection function and display fault information
|
Use environment
|
Temperature - 10 ℃ ~ 50℃ relative humidity below 90%
|
Physical size (mm)
|
2400×800×20002400 x 800 x 2000
|
Determine when you place an order
|
