304 Stainless Steel Female Threaded End 2 PC Ball Valve

Date:2020-06-10  Click:355   Share to:

  • NO.

    Name

    QTY(pcs)

    Material

    1

    Cap

    1

    CF8/CF8M

    2

    Body

    1

    CF8/CF8M

    3

    Ball

    1

    CF8/CF8M

    4

    Ball Seat

    2

    PTFE

    5

    Joint Gasket

    1

    PTFE

    6

    Stem Packing

    1

    PTFE

    7

    Thrust Washer

    1

    PTFE

    8

    Stem

    1

    304

    9

    Gland Nut

    1

    304

    10

    Handle

    1

    304

    11

    Stem Washer

    1

    304

    12

    Stem Nut

    1

    304

    13

    Plastic Sleeve

    1

    PVC



    Size

    1/4"

    3/8"

    1/2"

    3/4"

    1"

    1-1/4"

    1-1/2"

    2"

    A

    55

    55

    63.5

    68

    77.5

    90

    107

    123

    B

    40

    40

    45

    48

    56

    60

    75

    87

    D

    11.6

    12.7

    15

    20

    25

    32

    38

    50

    S

    20

    20

    25

    31.5

    39

    48

    55

    67

    L

    97

    97

    97

    115

    144

    144

    187

    187
