Pneumatu gate valve
Date:2020-06-10 Click:325 Share to:
DN(mm) |
L(mm) |
D(mm) |
D1(mm) |
D2(mm) |
b(mm) |
z-Фd(mm) |
H(mm) |
H1(mm) |
Do(mm) |
WT(kg) |
50 |
250 |
160 |
125 |
100 |
16 |
4-Ф18 |
950 |
570 |
180 |
36 |
65 |
270 |
180 |
145 |
120 |
18 |
4-Ф18 |
1050 |
596 |
180 |
53 |
80 |
280 |
195 |
160 |
135 |
20 |
8-Ф18 |
1080 |
635 |
200 |
72 |
100 |
300 |
215 |
180 |
155 |
20 |
8-Ф18 |
1145 |
645 |
250 |
90 |
125 |
325 |
245 |
210 |
185 |
22 |
8-Ф18 |
1210 |
685 |
250 |
120 |
150 |
350 |
280 |
240 |
210 |
24 |
8-Ф18 |
1300 |
720 |
320 |
132 |
200 |
400 |
335 |
295 |
265 |
26 |
12-Ф23 |
1660 |
940 |
400 |
258 |
250 |
450 |
405 |
355 |
320 |
30 |
12-Ф25 |
1790 |
1020 |
400 |
297 |
300 |
500 |
460 |
410 |
375 |
30 |
12-Ф25 |
1990 |
1150 |
450 |
420 |
350 |
550 |
520 |
470 |
435 |
34 |
16-Ф25 |
2090 |
1170 |
450 |
558 |
400 |
600 |
580 |
525 |
485 |
36 |
16-Ф30 |
2290 |
1325 |
500 |
840 |
450 |
650 |
640 |
585 |
545 |
40 |
20-Ф30 |
2485 |
1465 |
500 |
1110 |
500 |
700 |
705 |
650 |
608 |
44 |
20-Ф34 |
2640 |
1590 |
550 |
1380 |
600 |
800 |
840 |
770 |
718 |
48 |
20-Ф41 |
2940 |
1720 |
550 |
1620 |
700 |
900 |
910 |
840 |
788 |
50 |
24-Ф41 |
3450 |
1960 |
600 |
1966 |
800 |
1000 |
1020 |
950 |
898 |
52 |
24-Ф41 |
3650 |
2190 |
600 |
2282 |
900 |
1100 |
1120 |
1050 |
998 |
54 |
28-Ф41 |
3815 |
2400 |
800 |
2495 |
1000 |
1200 |
1255 |
1170 |
1110 |
56 |
28-Ф48 |
4000 |
2650 |
800 |
2760 |
