Ultra-thin type explosion-proof ionization smoke detector

This kind detector is intrinsically safe explosion-proof fixed temperature detector, be suitable for the risk place of explosive gas or dust. Its power is controlled. In order to effectively prevent the detonation of explosive gas.

Must be used with B401 base.

Rated intrinsically safe level: EEX IIC T5

Rate of temperature rise: 8.3℃/min（15F/min）

Indicator light: be seen from every angle.

Ambient temperature: －10℃～55℃

Ambient humidity: 5％～95％RH No Condensation

Boundary dimension: diameter*high＝102mm*35mm

Weight: 110g
