Input/Output Module

Share to:

Input/Output Module

General description:input/output module is a programmable control module that designed according to different working environments.
Features :It can act as linkage control executive component of controller and controlled equipments, and it can receive the response signal of controlled equipment after action.
Technical Specification:

Voltage	DC18～26V
Monitor Current	≤380uA
Alarm Current	≤2mA
contact capacity	DC24V/2A AC220V/0.5A
Amount Of Contact	normal open，normal closed
Operation Temperature	-10℃～+55℃
Relative Humidity	≤95%
Outline	120×85×34mm3
Weight	100g
Color	milky
Wiring	2 alarm-bus：T+、T-
