Shipyard Pedestal Crane
|
Main Technical Specification
|
Product No.
|
Main hoist
|
Aux hosit
|
Boom Angle (º)
|
Radius of Load (m)
|
Four part line reeving
|
Static Capacity (lbs)
|
Dynamic Capacity (lbs)
|
Stat/Dyn (lbs)
|
BMMDMSPEC-001
|
80.8
|
20
|
60,650
|
54,500
|
9,600
|
BMMDMSPEC-002
|
76.5
|
25
|
59,746
|
50,712
|
9,600
|
BMMDMSPEC-003
|
74.9
|
30
|
56,999
|
42,600
|
9,600
|
BMMDMSPEC-004
|
71.9
|
35
|
48,288
|
32,111
|
9,600
|
BMMDMSPEC-005
|
68.9
|
40
|
41,660
|
27,703
|
9,600
|
BMMDMSPEC-006
|
65.8
|
45
|
36,465
|
24,429
|
9,600
|
BMMDMSPEC-007
|
62.6
|
50
|
32,286
|
21,470
|
9,600
|
BMMDMSPEC-008
|
59.3
|
55
|
28,849
|
19,180
|
9,600
|
BMMDMSPEC-009
|
55.9
|
60
|
25,975
|
17,273
|
9,600
|
BMMDMSPEC-010
|
52.4
|
65
|
23,534
|
15,650
|
9,600
|
BMMDMSPEC-011
|
48.7
|
70
|
21,436
|
14,250
|
9,600
|
BMMDMSPEC-012
|
44.7
|
75
|
19,614
|
13,043
|
9,600
|
BMMDMSPEC-013
|
40.5
|
80
|
18,016
|
11,980
|
9,600
|
BMMDMSPEC-014
|
35.9
|
85
|
16,603
|
11,041
|
9,600
|
BMMDMSPEC-015
|
30.7
|
90
|
15,345
|
10,204
|
9,600
|
BMMDMSPEC-016
|
24.5
|
95
|
14,218
|
9,455
|
9,600
|
BMMDMSPEC-017
|
16.2
|
100
|
13,202
|
8,845
|
9,600
|
All the details including drawing and data are changeable according to customer's requirements.
|
|
|
