Singel Wheel Open Hook Pulley Block

Date:2020-06-30 Click:627 Share to:

Singel Wheel Open Hook Pulley Block

Product Number	Specified Load(t)	Test Load (kn)	Boundary Dimension					Wire Dia		Hook And Loop Cavity Size				Weight (kg)
			h	h1	b	lmax	$q	Suit	Max	d	0	r1	r
			mm							mm
BMMHDWRBL01	0.32	5.12	230	200	90	56.5	-	-	-	28	≥20	10	-	1.78
BMMHDWRBL02	0.32	5.12	230	200	90	56.5	-	-	-	28	≥20	10	-	1.64
BMMHDWRBL03	0.32	5.12	230	200	90	56.5	-	-	-	28	≥20	10	-	1.33
BMMHDWRBL04	0.32	5.12	230	200	90	56.5	-	-	-	28	≥20	10	-	1.99
BMMHDWRBL05	0.5	8	260	230	98	61.5	-	6.2	7.7	31.5	≥22	11	-	2.25
BMMHDWRBL06	0.5	8	260	230	98	61.5	-	6.2	7.7	31.5	≥22	11	-	2.03
BMMHDWRBL07	0.5	8	260	230	98	61.5	-	6.2	7.7	31.5	≥22	11	-	1.76
BMMHDWRBL08	0.5	8	260	230	98	61.5	-	6.2	7.7	31.5	≥22	11	-	1.53
BMMHDWRBL09	1	16	315	285	116	70.5	-	7.7	11	37.5	≥27	14	-	4.4
BMMHDWRBL10	1	16	315	285	116	70.5	-	7.7	11	37.5	≥27	14	-	4.03
BMMHDWRBL11	1	16	315	285	116	70.5	-	7.7	11	37.5	≥27	14	-	3.6
BMMHDWRBL12	1	16	315	285	116	70.5	-	7.7	11	37.5	≥27	14	-	3.23
BMMHDWRBL13	2	32	405	370	152	88	-	11	14	45	≥32	19	-	7.98
BMMHDWRBL14	2	32	405	370	152	88	-	11	14	45	≥32	19	-	7.4
BMMHDWRBL15	2	32	405	370	152	88	-	11	14	45	≥32	19	-	7.41
BMMHDWRBL16	2	32	405	370	152	88	-	11	14	45	≥32	19	-	6.8
BMMHDWRBL17	3.2	51.2	470	440	176	101	-	12.5	15.5	50	≥37	21	-	12.91
BMMHDWRBL18	3.2	51.2	470	440	176	101	-	12.5	15.5	50	≥37	21	-	12.16
BMMHDWRBL19	3.2	51.2	470	440	176	101	-	12.5	15.5	50	≥37	21	-	12.22
BMMHDWRBL20	3.2	51.2	470	440	176	101	-	12.5	15.5	50	≥37	21	-	11.48

Product Number	Specified Load(t)	Test Load (kn)	Boundary Dimension					Wire Dia		Hook And Loop Cavity Size				Weight (kg)
			h	h1	b	lmax	$q	Suit	Max	d	0	r1	r
			mm							mm
BMMHDWRBL21	5	80	570	540	212	117	-	15.5	18.5	60	≥42	26.5	-	23.79
BMMHDWRBL22	5	80	570	540	212	117	-	15.5	18.5	60	≥42	26.5	-	22.82
BMMHDWRBL23	5	80	570	540	212	117	-	15.5	18.5	60	≥42	26.5	-	19.85
BMMHDWRBL24	5	80	570	540	212	117	-	15.5	18.5	60	≥42	26.5	-	18.88
BMMHDWRBL25	8	128	730	685	280	141	-	20	23	75	≥56	33.5	-	41
BMMHDWRBL26	8	128	730	685	280	141	-	20	23	75	≥56	33.5	-	38.83
BMMHDWRBL27	8	128	730	685	280	141	-	20	23	75	≥56	33.5	-	36.4
BMMHDWRBL28	8	128	730	685	280	141	-	20	23	75	≥56	33.5	-	34.33
BMMHDWRBL29	10	160	810	775	316	159	-	23	24.5	85	≥61	37.5	-	62.98
BMMHDWRBL30	10	160	810	775	316	159	-	23	24.5	85	≥61	37.5	-	60.92
BMMHDWRBL31	10	160	810	775	316	159	-	23	24.5	85	≥61	37.5	-	54.1
BMMHDWRBL32	10	160	810	775	316	159	-	23	24.5	85	≥61	37.5	-	52.04
BMMHDWRBL33	16	224	1010	960	406	185	-	28	31	106	≥81	50	-	113.5
BMMHDWRBL34	16	224	1010	960	406	185	-	28	31	106	≥81	50	-	107.16
BMMHDWRBL35	16	280	150	1065	452	193	-	31	35	118	≥90	52.5	-	162.2
BMMHDWRBL36	16	280	150	1065	452	193	-	31	35	118	≥90	52.5	-	152.15
BMMHDWRBL37	32	512	1480	1400	580	240	-	35	38	140	≥106	-	-	300
BMMHDWRBL38	32	512	1480	1400	580	240	-	35	38	140	≥106	-	-

We also provide Singel Wheel Rings Type Block!!!
