Charasterists:
1.various voltage and frequency
2.capacity from 1Ton to 50Ton
3.speed:10m/min
4.rope length:100m to 2000m
5.safe for pulling and lift
6.various voltage and frequency can made by order.
7.used in building, bridge and port construction, dry dock slipway traction, factory, marine, mine, large-scale installation project, match lifting equipment and other hoist or traction engineering.
8.We could supply any length wire rope on drum as customers' demands.
Advantage
1.High versatility
2.Compactstructure
3.Smallvolume, lightweight, convenience in using and transferring
4.Driving stably
5.Very light noise
6.With big drum rope capacity to make you a wide range of choice for the lifting height or pulling length.
7.Adjustable lifting or pulling speed for different usage environment.
8.This kind of electric wire rope winch can be applied to the lifting or pulling operating in construction water conservancy, forestry, mining and quay places etc
Product Number
|
Model
|
Rated
pull (kn)
|
Rated speed
(m/min)
|
Drum rope
capacity (m)
|
Wire rope size
(mm)
|
Drum height
of center (mm)
|
Motor model and
power
|
Brake model
|
Product size (mm)
|
Net weight (kg)
|
BMMHDJMWC01
|
JM0.5
|
5
|
15
|
180
|
6*19,7.7
|
179
|
Y100L-4,2.2
|
TJ2-100
|
755*680*420
|
180
|
BMMHDJMWC02
|
JK0.5
|
5
|
25
|
180
|
6*19,7.7
|
179
|
Y100L-4,2.2
|
TJ2-100
|
755*682*420
|
180
|
BMMHDJMWC03
|
JM1B
|
10
|
15
|
170
|
6*19,9.3
|
221
|
Y132S-4,5.5
|
TJ2-150
|
780*840*435
|
265
|
BMMHDJMWC04
|
JK1B
|
10
|
25
|
170
|
6*19,9.3
|
221
|
Y132S-4,5.5
|
TJ2-150
|
780*840*435
|
265
|
BMMHDJMWC05
|
JM1.5B
|
15
|
16
|
230
|
6*19,11
|
255
|
Y132S-4,5.5
|
TJ2-200
|
1100*920*540
|
420
|
BMMHDJMWC06
|
JK1.5B
|
15
|
22
|
230
|
6*19,11
|
255
|
Y132M-4,7.5
|
TJ2-200
|
1100*920*540
|
440
|
BMMHDJMWC07
|
JM2C
|
20
|
18
|
230
|
6*19,12.5
|
295
|
Y132M-4,7.5
|
TJ2-200
|
1190*905*550
|
534
|
BMMHDJMWC08
|
JM3D
|
30
|
10,5
|
220
|
6*19,15.5
|
335
|
YZR160M-6,7.5
|
TJ2-200
|
1225*1037*560
|
650
|
BMMHDJMWC09
|
JK3D
|
30
|
20
|
220
|
6*19,15.5
|
335
|
Y160M-4,11
|
TJ2-200
|
1225*1037*560
|
620
|
BMMHDJMWC10
|
JM3B
|
30
|
16
|
220
|
6*19,15.5
|
360
|
Y160L-6,11
|
TJ2-200
|
1365*1133*625
|
720
|
BMMHDJMWC11
|
JK3B
|
30
|
24
|
220
|
6*19,15.5
|
360
|
T160L-4,15
|
TJ2-200
|
1365*1133*625
|
700
|
BMMHDJMWC12
|
JM5B
|
50
|
9
|
250
|
6*37,19.5
|
415
|
Y160L-6,11
|
YWZ-300/45
|
1568*1166*765
|
1200
|
BMMHDJMWC13
|
JK5B
|
50
|
15
|
250
|
6*37,19.5
|
435
|
YZR180L-6,15
|
YWZ-300/45
|
1568*1372*765
|
1400
|
BMMHDJMWC14
|
JZ5B
|
50
|
20
|
250
|
6*37,19.5
|
435
|
YZR200L-6,22
|
YWZ-300/45
|
1568*1450*765
|
1500
|
BMMHDJMWC15
|
JM8B
|
80
|
10
|
300
|
6*37,26
|
492
|
YZR180L-6,15
|
YWZ-300/45
|
1850*1570*875
|
2850
|
BMMHDJMWC16
|
JK8B
|
80
|
15
|
300
|
6*37,26
|
492
|
YZR200L-6,22
|
YWZ-300/45
|
1850*1630*875
|
2880
|
BMMHDJMWC17
|
JM10B
|
100
|
9
|
300
|
6*37,30
|
536
|
YZR200L-6,22
|
YWZ-300/45
|
2200*1744*986
|
3200
|
BMMHDJMWC18
|
JK10B
|
100
|
15
|
300
|
6*37,30
|
536
|
YZR225M-6,30
|
YWZ-300/45
|
2200*1800*986
|
3250
|
BMMHDJMWC19
|
JK12
|
120
|
12
|
300
|
6*37,32
|
556
|
YZR225M-6,30
|
YWZ-300/45
|
2200*1800*1006
|
3600
|
BMMHDJMWC20
|
JM16
|
160
|
9
|
400
|
6*37,36.5
|
760
|
YZR225M-6,30
|
YWZ-400/90
|
2720*2265*1310
|
5200
|
BMMHDJMWC21
|
JK16
|
160
|
20
|
400
|
6*37,36.5
|
850
|
YZR280M-6,75
|
YWZ-400/90
|
2650*3050*1500
|
5800
|
BMMHDJMWC22
|
JK20
|
200
|
10
|
450
|
6*37,39
|
950
|
YZR250M-6,45
|
YWZ-400/90
|
3000*3850*1700
|
7500
|
BMMHDJMWC23
|
JM30
|
300
|
8.5
|
450
|
6*37,47.5
|
1100
|
YZR280M-6,75
|
YWZ-500/90
|
3800*4700*2000
|
9200
|
WE CAN ALSO PROVIDE ALL KINDS OF HOISTING WINCH U WANT
Contact us to know more !!!
|
