Pressure Vessel Steel Plate

Introduction:

Pressure vessel plate also named as boiler steel plate.These steel plates mainly used for building boilers and pressure vessels such aspetroleum, chemical industry, power plant, boiler, uses in manufacturing the reactor, the heat interchanger, the separator, the spherical tank, the oil gas storage holder.

Rolling specifications range:Thickness within 6-300mm,Width within 1500-4000mm,Length within 4500-14000mm.

Additional technical terms: Heat treatment such as Normalized,NACE included HIC and SSCC test,UT according to A435/A435M, A577/A577M, A588/A588M and so on.

Mainly Application:

Widely used in petroleum, chemical industry, power plant, boiler, etc, and used to make the reactor, heat exchanger, separator, spherical tank, YouQiGuan, liquid tank, nuclear power reactors YaLiKe, boiler drum, liquefied oil steam bottle, high-pressure hose, spiral turbine hydropower station equipment and components.

Product Description Information:

STANDARD	STEEL GRADE
EN10028	P235GH,P265GH,P295GH,P355GH,16Mo3 P275N,P275NH,P275NL1,P275NL2,P355N,P355NH,P355NL1,P355NL2,P460N, P460NH,P460NL1,P460NL2 P355Q,P355QH,P355QL1,P355QL2,P460Q,P460QH,P460QL1,P460QL2, P500Q,P500QH,P500QL1,P500QL2,P690Q,P690QH,P690QL1,P690QL2 P355M,P355ML1,P355ML2,P420M,P420ML1,P420ML2,P460M,P460ML1,P460ML2
DIN 17155	HI,HII,17Mn4,19Mn6,15Mo3,13CrMo44,10CrMo910
ASME ASTM	A203/A203M SA203 Grade E,SA203 Grade F,SA203 Grade D,SA203 Grade B,SA203 Grade A A204/A204M A204 Grade A,A204 Grade B,A204 Grade C A285/A285M A285 Grade A,A285 Grade B,A285 Grade C A299/A299M SA299 Grade A,SA299 Grade B A302/A302M SA302 Grade A,SA302 Grade B,SA302 Grade C,SA302 Grade D A387/A387M SA387Gr11CL1,SA387Gr11CL2,SA387Gr12CL1,SA387Gr12CL2, SA387Gr22CL1,SA387Gr22CL2 A515/A515M (S)A515Gr55,(S)A515Gr60,(S)A515Gr65, (S) A515Gr70 A516/A516M (S)A516Gr55,(S)A516Gr60,(S)A516Gr65,(S) A516Gr70 A533/A533M SA533GrACL1/CL2/CL3/CL4,SA533GrB A537/A537M (S)A537CL1, (S)A537CL2, (S)A537CL3
JIS	SB410,SB450,SB480,SB450M,SB480M SPV235,SPV315,SPV355,SPV410,SPV450,SPV490
GB	GB713 Q245R,Q345R,Q370R,18MnMoNbR,13MnNiMoR,5CrMoR,14Cr1MoR, 12Cr2Mo1R,12Cr1MoVR GB3531 16MnDR,15MnNiDR,09MnNiDR

Note:
1. Can Z15-Z35 each brand production of layered tear resistance (thickness direction performance steel plate.)
2. Production specifications: 8 mm-40 mm thickness and width 1500 mm to 3900 mm, length of 3000 mm to 18000 mm. Agreement by both parties, which can supply the more big specifications of the steel plate.
3. According to the properties and delivery state user needs, steel plate can be hot rolling and controlled rolling, annealing, normalizing, tempering, is fire and tempering, conditioning and state delivery.
