Product Description
The RAI900 rudder angle indicator system is a set of devices for displaying the steering angle information of a ship in real time in a place such as a bridge, a cockpit, and the like where a rudder angle information is to be displayed. The complete set of devices should complete the rudder angle of the collection, digital processing, digital transmission, display (digital and analog band display), control (such as the brightness of the display) and other functions.
Technical Parameters
System rudder angle |
Display error is not greater than 1 ° (relative to the rudder blade actual rudder angle)
|
Power supply
|
DC24V
|
Rudder angle measurement range
|
－50°～＋50°
|
Rudder angle sampling resolution
|
0.1°(12 bits AD)
|
Rudder angle data transmission rate
|
5 times / s
|
Default linear correction sampling point step size
|
5°
|
Data output interface
|
RS-422 Standard
|
Output data format
|
Comply with IEC-61162 standard
|
Ambient temperature
|
－15℃～＋55℃
|
Humidity
|
93% ± 2% (ambient temperature 25 ℃ ~ 40 ℃)
|
|
