Engine Telegraph

Features
The slave clock transmitter is connected to the receiver for a 4-pin cable connection.
   While the two sides of the work state, and the instructions can be two-way transmission.
   Accident car alarm: the two sides are not synchronized when the panel lights flashing and sound and light alarm, once synchronized, automatically revoke the sound and light alarm.
   Power failure alarm: power supply will be issued a sound and light alarm.
   Dimming function: can be used with the outside world to adjust the intensity of the cab signal bell panel lights brightness.
   External functions: transmitter and receiver in addition to built-in sound and light alarm, the other there are external sound and light alarm interface.

Operating instructions
   Press the Carriage button on the Clock Transmitter, and the Stop Indicator on the Clock Transmitter panel is off, the vehicle indicator flashes, the buzzer "drops", "drops". This signal is sent to the receiver through the wire, so that the receiver panel on the parking indicator light at the same time, the car lights flashing, buzzer "drop", "drop" tweet, the receiver passive contact closure. Press the car button on the delivery clock receiver, the parking indicator on the receiver panel is off, the vehicle indicator light stops flashing, it changes to constant, the buzzer stops "drops", "drops", the receiver is passive Contact open. This signal is sent to the transmitter through the wire, so that the transmitter panel lights on the car to stop flashing, into a straight, the buzzer stop "drop", "drop" tweet.
   Finished the car, parking, into a, into the two, into the three, into the four, back one, back two, back three, back four files of the same operation.

Technical Parameters
