Model
|
BMMEENPAP-005
|
Type
|
Autopilot
|
Power
|
AC380V、50Hz；220V、50Hz；DC24V
A:three –phase 380V, ±5%
B:220V、50Hz，±5%
C:DC24V、3A,+10% ～ -10%
|
Steering
|
Automatic, with the dynamic and manual;
|
steering precision
|
≤1º
|
Ineffective area
|
0.5 º ~ 2 º adjustable;
|
Steering mode
|
±40º
|
Other
|
DHART mode can double pump
|
No.
|
Name
|
Type
|
Quantity
|
protect
|
1
|
Cab main instrument
|
DD101-ZT
|
1
|
IP22
|
SC9-K
|
DD102-ZT
|
2
|
1 # pump start box
|
SC9-K
|
1
|
3
|
2 # pump start box
|
SC10-K
|
1
|
4
|
Steering gear alarm box
|
CKD-4
|
1
|
5
|
Feedback rudder angle transmitter
|
DD101-WK
|
1
|
IP56
|
6
|
Automatic feedback transmitter
|
RF45X
|
1
|
Alarm range :Dynamic power failure, overload, phase failure, power failure control, low oil level, oil temperature, oil filter clogging,
pressure difference, compass failure; and an alarm test function and automatic reset function after silencer;
|
