Technical Parameters
Screen display |
9 inch color LCD display, 800 × 480 pixels;
|
Echo color
|
Standard (4 colors 32 levels gradient composition), gray, reverse, green and other modes of choice;
|
Display mode
|
Front channel display, rear channel display, dual channel display, version information, simulation
|
Automatic mode
|
Automatic range, automatic sensitivity;
|
Display the waveform
|
In any case set, the display waveform will not be interrupted;
|
Interference suppression
|
Automatically suppress the same frequency interference signal and other unwanted signals;
|
Cursor operation
|
Any depth measurement of the screen;
|
Depth offset
|
± 5 meters;
|
Alarm mode
|
Depth alarm
|
Resolution
|
0.022 m
|
Split screen mode
|
Vertical
|
Working frequency
|
200KHz single frequency
|
Depth range
|
0.4 to 100 meters
|
Picture speed
|
1 to 10
|
Background color
|
White, blue, black
|
Output Power
|
250W
|
Weight
|
1.26kg / 2.42kg (including probe)
|
Power supply
|
DC 8.5V～40V 7W
|
Use the environment
|
0 to 50 ° C, 95% relative humidity below
|
Storage temperature
|
-20~70℃
|
Degree of protection
|
IP64
|
|
|
