Features:
1. The world's most advanced acoustic related technologies
2. In the corresponding range can make agile accurate scale reading
3. 32 mm diameter of the probe in the maximum extent reduced the bottom part of the installation work
4. Bottom installation device can be widely compatible YuKangShi water SAL Imcor and SAL R1 before all kinds log products
5. A variety of different types and kinds of bottom parts can be excellent applied to ship the existing reconstruction,
or even making sea change operation and maintenance.
Main technical performance and specification:
Effective distance
|
Under the sonde 130mm
|
Frequency
|
3.840 and 4.196MHz
|
Speed range
|
±50knot
|
Speed accuracy
|
<0.1kont or <1%
|
Distance accuracy
|
<1%
|
Minimum depth
|
Under the sonde 3 meter
|
Electronics unit BMMENGSL-01
Unit code
|
703800
|
Speed output
|
IEC61162-1(NMEA0183) maximum 100Ω=10SD displays
|
Simulation speed output
|
1×0.1VDC/knot (maximum load 5mA)
|
Pulse speed output
|
200p/NM
|
Status output
|
One way Loss of electrical contact output
|
Display power
|
Maximum 3 SD displays
|
Power requirement
|
230/115VAC 50-60HZ
|
Rated power
|
30VA
|
Work condition
|
IEC 60945
|
Size
|
360(±30)×360×170mm
|
Weight
|
10.5kg
|
Color
|
RAL7032
|
Main display
SD4-3
|
Digital display Voyage and total mileage accumulated
|
Unit code
|
704043
|
Size
|
144×144×16mm
|
Weight
|
0.6kg
|
Sonde (TRU R1)
Size
|
32mm×160mm
|
Sonde (TRU R1 )
|
30 meters cable
|
Unit code
|
705050
|
Weight
|
3.7kg
|
Sonde (TRU R1)
|
40 meters cable
|
Unit code
|
705051
|
Weight
|
3.9kg
|
Bottom device
MSSBSV
|
Single bottom valve
|
Unit code
|
71-21540-00
|
Weight
|
24kg
|
MSDBSV
|
Double bottom valve
|
Unit code
|
71-21560-00
|
Weight
|
24.2kg
|
MSSB
|
Single bottom installed flange
|
Unit code
|
71-21520-01
|
weight
|
20.1kg
|
