Marine radar with 12.1 Color LED display
Model:BMMNCMR005
Product discription
1. Confirm with the Regular inspection of ships and offshore installations for domestic navigation ships.
2.Confirm with the IEC60936 Maritime navigation and radio communication equipment and systems–Radar.
3. 12.1” Color LED display.
4. 4Ft(1.2m) high performance slotted waveguide antenna.
5. Advanced auto-tune function help to get better echo picture.
6. True motion echo trail.
7. ARPA function can capture and track 50 targets.
8. AIS interface, and display up to 200 AIS targets.
9. Distinguish closer targets while not missing farther targets.
Product specifications
Antenna Radiator Unit
|
Type
|
Slotted waveguide array
|
Length
|
4ft（1.2m）
|
Rotation Speed
|
24 rpm
|
Wind Load
|
100kt
|
Hor. Beam Width
|
0.9°～1.3°
|
Ver. Beam Width
|
20°～28°
|
Frequency
|
9410 ± 30 MHz (X-band)
|
Output Power
|
4KW
|
Environment Temp.
|
-25°C to +70 °C (-13 °F to +158°F)
|
Waterproof
|
IPX6
|
Display Unit
|
Screen Size
|
12.1 inch
|
Resolution
|
866*600
|
Effective Diameter
|
184mm
|
Display Mode
|
Real/Clear/Sea/Strong
|
Echo Mode
|
Single color/Multi Color
|
Direction Mode
|
North Up/Heading Up
|
Move Mode
|
True/Relative
|
Measurement Unit
|
km/nm
|
Range
|
0.125/0.25/0.5/0.75/1.0/1.5/2.0/3.0/ 6.0/12/24/48
|
Rings
|
0.0625/0.125/0.125/0.25/0.25/0.25/0.375/0.5/1.0/2.
0/4.0/8.0/16
|
Min. Range
|
25m
|
Range Discrimination
|
25m
|
Trail Mode
|
True / Relative
|
Trail Length
|
Short/Middle/Long
|
ARPA Acquisition
|
Auto/Manual
|
ARPA Number of Targets
|
20
|
ARPA Information
|
Distance/Speed/CPA/TCPA etc.
|
AIS Number of Targets
|
100
|
AIS Information
|
Distance/Heading/CPA/TCPA etc.
|
Start Time
|
90S
|
Data Input
|
GPS/Gyro/AIS/Sounder
|
Data Output
|
IEC61162 NMEA0183 ARPA
|
Environment Temp.
|
-15°C to +55 °C (5 °F to +131°F)
|
WaterProof
|
IPX5
|
Power Supply
|
DC12-36 250W
|
|
