These series marine satellite antenna can track a satellite that you want to receive in the fastest time by adjust its Azimuth angle ,
elevation angle, and polaziration angle. So you can enjoy the best broadcast possible. 450P antenna will bring you exciting Digital TV(HD) enteraiment without interruption even as you cross the pacific ocean.
The unique technology equips the mariner with superior high definition and sound quality performance.
The true definition of elegance on the sea or river.
Mode
|
340
|
450
|
450P
|
600
|
600P
|
Antenna type
|
|
parabola
|
Parabola size
|
340mm
|
450mm
|
450mm
|
600mm
|
600mm
|
Antenna size (D x H)
|
390mm x 380mm
|
550mm x 500mm
|
550mm x 500mm
|
750mm x 700mm
|
750mm x 700mm
|
Mini.EIRP
|
51dBW
|
49dBW
|
49dBW
|
47dBW
|
47dBW
|
Frequency band
|
High band 11.7-12.75GHz,Low band 10-10.7GHz
|
Antenna gain
|
31dBi
|
33dBi
|
33dBi
|
35dBi
|
35dBi
|
HDTV Compatible
|
Yes
|
Yes
|
Yes
|
Yes
|
|
Polarization
|
RHCP/VHCP,V&H
|
Stablized type
|
2-axis
|
2-axis
|
3-axis
|
2-axis
|
3-axis
|
Elevation range
|
0°-90°
|
0°-90°
|
0°-90°
|
0°-90°
|
0°-90°
|
Azimuth
|
680°
|
680°
|
680°
|
680°
|
680°
|
GPS
|
No
|
No
|
option
|
option
|
option
|
Power supply
|
|
AC90-250V(DC9-30V)
|
Work watt
|
20w
|
24w
|
28w
|
36W
|
40W
|
Work temper.
|
（-22℃～65℃）
|
Accessory
|
IDU, cable
|
Install type
|
4x M8 bolts
|
4x M8 bolts
|
4x M8 bolts
|
4x M10 bolts
|
4x M10 bolts
|
Update port
|
|
RS232
|
Cover material
|
ABS
|
Polarization angle range
|
manual
|
manual
|
automatic
|
manual
|
automatic
|
Waterproof
|
IPX65
|
package
|
paper
|
paper
|
paper
|
paper
|
paper
|
package weight
|
5.5kg
|
10kg
|
11kg
|
19.5kg
|
20.5kg
|
package dimension
|
480x480x550mm
|
700x700x795mm
|
700x700x795mm
|
825x825x875mm
|
825x825x875mm
|
|
