Satellie TV Antenna 150cm
150 marine satellite tv antenna is that High-end products TVRO for worldwide ocean-going vessels.
This is use three-axis stabilized mechanical structure of precision,four-axis tracking structure and with a 150cm large diameter parabolic antenna,
In harsh Marine environment under the condition of complete accurate automatic tracking satellite and signal transmission function,
has reached to ensure uninterrupted broadcast of offshore high-definition TV and radio programs, to become the perfect choice for high-end customers.
150 cm antenna aperture, make its coverage has greatly increased, and in star functions, basic can achieve no blind spot coverage around the world.
Inteam
|
Parameters
|
Inteam
|
Parameters
|
Technical principles
|
Helical Scan
|
Diameter / height
|
Φ210cm x 206cm
|
Satellite band
|
Ku-band geostationary satellites
|
Reflective surface diameter
|
150cm
|
Downlink frequency range
|
3000 MHz～4800 MHz
|
Weight
|
150kg
|
Polarization
|
Linearly polarized / circular polarization
|
Input voltage
|
AC220V
|
Satellite landing field
|
≥40dBw
|
Rated Power
|
200W
|
Antenna gain
|
33 dBi
|
Operating temperature
|
-22℃～70 ℃
|
Elevation range
|
-15º～135º
|
Housing material
|
FRP
|
Azimuth range
|
0º ～680º
|
Shell color
|
white
|
Roll range
|
±35º
|
Installation
|
Screws Fixed
|
Pitch tracking speed
|
>25º/s
|
Accessories
|
Control box,cable
|
Azimuth tracking speed
|
>25º/s
|
GPS
|
Internal
|
Roll tracking speed
|
>25º/s
|
interface
|
RS232
|
Initial satellite lock
|
<100s
|
RF interface
|
4 x F type
|
Signal recovery Lock Time
|
<5s
|
Data Line Interface
|
5 wire
|
|
