Type
|
HX2010
|
Working voltage
|
DC 12V+30/-10%
|
Channel Capacity
|
57 international channels
|
Channel spacing
|
25KHz
|
Frequency generation method
|
Synthetic
|
Dimensions
|
175 (W) × 79 (H) × 130 (D) mm
|
Net weight
|
175 g
|
Receiver
|
Multi-channel receiver
|
Dual conversion superheterodyne receiver design.
|
Frequency range
|
156.300-163 .275 MHz
|
IF Frequency
|
21.7MHz; 450KHz
|
Maximum usable sensitivity
|
≤-4.5dBuV EMF (0.3uV). Of 20dB/SINAD
|
Adjacent Channel Selectivity
|
≥ 70dB
|
Spurious response rejection
|
≥ 70dB
|
Intermodulation rejection
|
≥ 68dB
|
Spurious Radiation
|
≤ 2nW
|
Current
|
0.9 Amps (Max Audio)
0.4 Amps (STBY)
|
Audio Response
|
deviation from 6dB / octave-emphasis characteristic curve +11-3 dB
Range (300-3000Hz)
|
Residual Noise Level
|
≤-40dB
|
Audio output power
|
3.5W less than 10% distortion with an 8 ohm external speaker
2W internal speaker only
|
Channel Technical characteristics
|
Frequency
|
CH70 (156.525MHz)
|
Sensitivity
|
≤-4.5dBuV EMF (0.3uV). Of 20dB/SINAD
|
Bandwidth
|
16KHz
|
he first IF frequency used
|
17.9MHz
|
The second IF frequency used
|
455KHz
|
Adjacent Channel Selectivity
|
≥ 70dB
|
Spurious response rejection
|
≥ 70dB
|
Intermodulation rejection
|
≥ 68 dB
|
Modulation Mode
|
16KOG2B
|
Spurious Radiation
|
≤ 2nW, 9KHz to 2GHz
|
Transmitter
|
Type of emission
|
16KOG3E (Voice) 13K5G2B (DSC)
|
Frequency range
|
156.025-157 .425 MHz
|
Maximum output power
|
25W, 1W into 50 Ohms
|
Audio distortion
|
≤ 10%
|
Audio Frequency Response
|
deviation from 6dB / octave-emphasis characteristic curve +1 /-3dB range (300-3000Hz)
|
Residual modulation
|
≤-40dB
|
Deviation:
|
5KHz maximum peak
|
Spurious Radiation
|
≤ 0.25uW
|
Current
|
≤ 5 Amps (25W)
|
