As LED and fluorescent lights are becoming more and more popular in the same project, but the dimming principles
of LED and traditional fluorescent lights are different, so we developed a new 0-10V dimming controller which has solved the compatible problem of fluorescent dimming controller and LED illumination;
this controller can dim both fluorescent and LED lamps at the same time.
Specification :
Model
|
BM-435
|
Input Voltage
|
DC12V-DC24V
|
Input Signal
|
0-10V analog dimming signal
|
Max Load Current
|
5A/CH×3CH
|
Max output power
|
180W(12V) / 360W(24V)
|
Output Signal
|
Constant voltage PWM
|
Product Dimension
|
L121×W39×H39(mm)
|
Package Size
|
L123×W42×H42(mm)
|
Gross Weight
|
100g
|
Basic Features:
1. 0 - 10V to PWM dimming signal conversion.
2. Optical isolation protection for input & output;
3. Compatible with many brand dimming systems.
4. Working voltage from DC12V~DC24V
5. YH-435 Model: 3 output channels, 5A per channel, 15A totally;
6. Multi units can be worked together or use our power repeaters to control more lamps.
|
