Brief Introduction
LED Power Repeater is suitable for all of our company's power-output style controllers’ power expansion, it accepts PWM control, the control quantity of LED lights would be twice as much by adding one more power repeater, unlimited quantity of power repeater to be connected theoretically. Also, the power repeater of constant voltage model and constant current model could be connected freely, suitable for synchronized controlling on different LED lamps.
Specification:
Model
|
BM-933
|
Input voltage
|
DC12V～DC24V
|
Max load current
|
3A/CH×3
|
Max output power
|
108W(12V) /216W(24V)
|
Dimension
|
L121×W39×H39(mm)
|
Package Size
|
L123×W42×H42(mm)
|
Weight (G.W)
|
130g
|
Basic Features
1.3 Channels RGB output, 3A/CH, total 9A .
2.Accept PWM control.
3.Unlimited connection quantity theoretically, unlimited power output expansion.
4.Maximum length from controller to repeater can be 500meters
|
