Function introduction:
1. Navigation, signal light controller is used to control navigation, signal light work condition controller.
It through the analog panel controller button and light to control and monitor the actual ship navigation, signal light working condition.
2. Fog horn: fog horn controller has automatic control, manual control, fog light control, whistle heater control function.
3. Distribution box: Used to control the drive control station equipment power supply.
4. Steering, operating machine function: To realize the rudder and host of normal and emergency control.
5. Communication command function: A control station is equipped with a command telephone, very high frequency, etc.,
so that each cabin parts for communication.
Main performance specifications
Environmental conditions:
Environment temperature: －10℃~+＋55℃
Air related humidity: ≤95%
Other air conditions: A vibration impact salt fog, mist and mould influence
Tilt and rocking: rolling ±22.5º, pitch±10º(cycle 3~6s) crabwise ±22.5º, raked±10º
Voltage and power:
Input AC220V: 50Hz ,24V, AC380V
Stable voltage: +6%~－10%
Transient voltage: ＋20%, 1.5s recovery
Stable frequency: ±5%
Transient voltage: ±10%, 5s recovery
Input DC 24V: ±20% rated voltage
The main base type product sample:
